Brand Twist fiber optic cable Product Structure Diagram
Product Overview The twisted multi-core fibre optic cable is sufficiently robust for amusement park rides, extremely cold weather and underwater applications. The fibre is wound around a highly reflective PVC core, providing flexible and stable maximum light output. |
|
Product Features
Cold light source, no ultraviolet rays | Safe and reliable | Low energy consumption, environmentally friendly and energy saving | flexible transmission | High brightness |
Basic Parameters
Core Materials | NA | coating material | Sheathing material | optical structure | Core Refractive Index |
PMMA | 0.5 | Fluorinated Polymer | PE |
Core Refractive Index | 1.49 |
Product Model
Model | core count | optical cable diameter(mm) | Product Structure Diagram |
RS-TSL-750-42 | 42*Φ0.75 | Φ10 |
|
RS-TSL-750-84 | 84*Φ0.75 | Φ14 |
|
RS-TSL-750-126 | 126*Φ0.75 | Φ18 |
|
Application Areas
Indoor lighting, water feature lighting, pool lighting, architectural lighting, architectural heritage lighting, flammable and explosive lighting.
